Overview of Series 2000, 3000, and 4000 Differential Pressure Gauges

1. Magnehelic® Differential Pressure Gauge (Series 2000):
   • The Magnehelic gauge is the most popular and reliable gauge for measuring low differential pressures.
   • It features a simple, easy-to-read dial and provides accurate readings of low pressures across a range of 0.25 to 60 inches of water column (in. w.c.).
   • Applications: Commonly used in HVAC systems, cleanrooms, filter monitoring, and other low-pressure applications where high accuracy is essential.
2. Capsuhelic® Differential Pressure Gauge (Series 3000):
   • The Capsuhelic gauge is designed for direct readings of differential pressure and static pressure.
   • It is unique for its capsule design, providing pressure ranges from 0 to 50 PSI, suitable for applications that require higher pressures than Magnehelic gauges.
   • Applications: Used in applications such as filtration, fan and blower pressure, and liquid level monitoring.
3. Photohelic® Differential Pressure Switch/Gauge (Series 4000):
   • This series combines the functionality of a pressure gauge and a switch, allowing it to control processes as well as provide pressure readings.
   • The Photohelic gauge is unique in that it includes setpoints, which can activate alarms or other control systems when the pressure goes above or below the desired range.
   • Applications: Ideal for critical applications like dust collection, cleanroom monitoring, and process control in industries such as pharmaceuticals and food processing.

Key Benefits and Features

1. Accurate Pressure Readings: Each model is calibrated to ensure precision in differential pressure measurements, critical for system efficiency.
2. Durable Design: Constructed from high-quality materials to handle the demands of industrial environments.
3. Multiple Ranges and Configurations: Available in various pressure ranges to suit specific requirements, from low-pressure HVAC needs to high-pressure process monitoring.
4. Control Capabilities: The Series 4000 Photohelic gauge offers switching capabilities, enabling real-time process adjustments.

Application Highlights

• HVAC and Cleanroom Monitoring: The Magnehelic and Photohelic gauges monitor differential pressure to maintain air quality and system efficiency.
• Industrial Filtration: The Capsuhelic and Photohelic gauges track filter conditions, alerting operators to necessary filter changes and preventing system downtime.
• Process Control: The Photohelic gauge’s switch functionality helps automate processes by triggering controls when pressure deviates from set parameters.

Why Choose Dwyer’s Differential Pressure Gauges?

• Reliability and Precision: Known for high accuracy and durability, Dwyer gauges are a trusted choice for pressure monitoring.
• Broad Application Scope: Suited to a wide array of industries, including pharmaceuticals, cleanrooms, HVAC, and industrial processing.
• Enhanced Process Control: The switching feature of the Photohelic gauge adds another layer of operational control for critical applications.

For industries where accurate differential pressure monitoring is vital, Dwyer’s Series 2000, 3000, and 4000 Differential Pressure Gauges offer tailored solutions to keep systems running efficiently and safely. Whether you need simple pressure readings or integrated control capabilities, Dwyer’s gauges provide reliable performance across multiple industrial applications.
